UMI Performance Tubular K-Member, Coil Over | 2402-BCamaro1982-92

UMI Performance Tubular K-Member, Coil Over | 2402-BCamaro1982-92
$1,139.99 kt
NEWARRIVING SOONEstimated Ship Date 12/09/2020 (If Ordered Today)
Model: 3248120
Select a Vehicle or refer to the Vehicle Fitment Tab below to verify that this part fits your vehicle.
[More Info]

  • Fits 1982 To 1992 Chevrolet Camaro
  • Fits 1982 To 1992 Pontiac Firebird
  • 20 lbs Lighter Than Stock
  • Double Tube Construction For Superior Strength
  • Strong 3/16” Thick Mild Steel Engine &amp Suspension Mounts Held Together With 1-1/2” Dia
  • DOM Tubing
  • CNC Machined &amp Jig-Built For No Hassel Installation
  • MIG And TIG Welded For Clean Looks &amp Superior Strength
  • Direct Bolt-In Design Can Be Used With Factory, UMI Or Other Aftermarket A-arms As Well As
  • Factory Or Aftermarket Springs
  • Includes Six New Grade 10.9 Mounting Bolts
  • Durable Red Or Black Powder Coat
  • Modular Design Allows Use Of Coil-Overs And/Or LS Mounts For Minimal Cost
  • Manufactured With Pride In Philipsburg, PA - USA

We all know weight equals horsepower. UMI’s direct bolt-in replacement K-member
instantly removes 20 lbs of front end weight from your ride and helps your existing
horsepower work for you. Strong dual tube construction and a host of high-strength
features ensure the P/N 2404 will survive street use, drag strip blasts and autocross action.
The K-member is fabricated from CNC machined 3/16” mild steel held together by a strong
dual tube lower section. Included fabricated motor mounts are used to bolt any LSX engine
to the precision machined mounting pads while both factory and aftermarket suspension is
located by strong boxed mounting points. Lightening holes are CNC machined into the
mounting plates and the tubular construction provides added clearance for aftermarket
exhaust. The modular design permits coil-over use as delivered or can be converted to stock
spring and strut use by removing the top bracket and adding a UMI spring perch to convert
to factory style springs. Street and track testing on our ’89 IROC test car has shown this K-
member to be strong, reliable and a great upgrade for your high performance ride. Available
in tough powder coated red or black finish. Manufactured with pride in Philipsburg, PA –

Coil Over Application Only: P/N 2404 is designed to be used with coil over set ups only and
does not allow the use of factory springs. P/N 2402 can be converted to accept factory style
springs by purchasing spring perch kit P/N 2405.

Note: Low mounted factory LS A/C needs relocated when running a UMI tubular k-member,
we recommend purchasing a A/C relocation kit. K-member was designed around the LS1 oil
pan and also works with the Holley 302 oil pan. Other oil pans may not clear. P/N 2404 k-
member can also be used with a factory SBC engine by not installing the included LSX motor
mount stands.

Vehicle Fitment:

The Vehicle Fitment Guide is to be used as a general reference. The data has been provided by our suppliers and manufacturers and may contain errors or incorrect data. Always refer to a professional to verify correct fitment for your vehicle.
Make Model Years
Chevrolet Camaro 1993 - 1999
