Hedman Performance Swap-In-A-Box complete engine swap kits feature everything you need to transplant that new engine into your ride. They include a set of application-specific headers (painted or ceramic coated), motor and transmission mounts, and some kits contain oil filtration components. By matching up these parts by vehicle, Hedman ensures a swap with minimal modifications needed for installation. Give your ride a heart transplant using one of these turnkey Swap-In-A-Box complete engine swap kits!
- TUBE DIAMETER: 1-3/4"
- COLLECTOR STYLE: Ball and Socket Style (Gasketless)
- AIR CONDITIONINGYes
- AUTOMATIC TRANSMISSION - COLUMN: No
- AUTOMATIC TRANSMISSION - FLOOR: Yes
- MANUAL TRANSMISSION - COLUMN: No
- MANUAL TRANSMISSION - FLOOR: No
- BAFFLED: No
- COLLECTOR SIZE: 3"
- EMISSIONS NOTES: NOT LEGAL FOR STREET USE ON '76-LATER MODEL YEARS! Legal for off-road use only.
- ENGINE: Chevy LS Series
- EXHAUST SYSTEM DIA: 3"
- FINISH: Uncoated Headers
- FLANGE THICKNESS: 3/8"
- HEAD FLANGE GASKET: Yes
- INSTALLATION NOTES: Requires relocation of Oil Filter. Pan has integrated -10AN inlet and outlet ports. Please see Trans Dapt # 4012, 4014 & 4016.
- O2 SENSORS: No
- PICKUP #2522
- POWER STEERING: Yes
- PRODUCT DETAILS: Engine swap kit for installing an LS engine into 1975-81 Chevy Camaro and Pontiac Firebird
- SUMP STYLE: Wet Sump
- TRANSMISSION COMPATIBILITY: Automatic Transmission
- TRANSMISSION NOTES: Not for use with 4L80E or 4L85E Transmissions.
- VARIATIONS 42031, 42032, 42033.
- DIPSTICK PORT: No
- PICKUP INCLUDED: Yes
- SUMP LOCATION: Rear
- KICKED OUT: No
- WITH A.I.R. SYSTEM: No
- WITH EGR: No
- REDUCER OUTLET SIZE: 3" to 3" Exhaust
- OIL PAN DEPTH (IN): 2" at front of Oil Pan; 6" at Rear Sump
- TUNED: NO
- REDUCERS INCLUDED: Yes
- GASKET OR SEAL INCLUDED: Yes
- DRAIN PLUG INCLUDED: Yes
- WINDAGE TRAY INCLUDED: No
- OIL PAN BOLTS INCLUDED: Yes
- BOLTS/STUDS INCLUDED: Yes
- CRANK SHAFT WIPER INCLUDED: No
- INSTALLATION HARDWARE INCLUDED: Yes
- TRANSMISSION MOUNT/CROSSMEMBER INCLUDED: 6419
- MOTOR MOUNTS INCLUDED: 4203
- MOUNTING HARDWARE INCLUDED: Yes
- HEADER FASTENERS INCLUDED: Yes
- COLLECTOR BOLTS INCLUDED: Yes
- Y-PIPE INCLUDED: No
- PRIMARY TUBE GAUGE: 16g
- PRIMARY TUBE DIAMETER (IN): 1.75"
- PACKAGE CONTENTS: Headers, Head Flange Gaskets, Head Flange Bolts, Collector Bolts and Gaskets, Socket Style Exhaust System Adapters (Reducers); Transmission Crossmember, Oil Pan, Oil pan gaskets, Oil pick-up tube, Pan Bolts; Frame Mounts, Engine Mounts and Hardware.
- HEADER MATERIAL: Mild Steel
- HEADER FINISH: Uncoated
- GASKET #27470
- CYLINDER HEAD: Factory Style
- O2 PROVISION: No
- OIL PAN CAPACITY: 5 Qts. Capacity
- OIL PAN MATERIAL: Steel
- TRANSMISSION MOUNT TYPE: Crossmember
- OXYGEN SENSOR BUNG INCLUDED: No
- VEHICLE USE: F-Body (GM) 1975-81
- SUMP DIMENSIONS: Driver Side: 4 3/4" x 3" x 8 1/4" Passenger Side: 7" x 8 1/4"
- OIL PAN INCLUDED: 1108
- HEADERS INCLUDED: 68720
