UMI Front Suspension Package, Stage 5 With Chrome Moly A-Arms, LS1, 1998-2002
UMI Front Suspension Package, Stage 5 With Chrome Moly A-Arms, LS1, 1998-2002 UMI Front Suspension Package, Stage 5 With Chrome Moly A-Arms, LS1, 1998-2002

UMI Front Suspension Package, Stage 5 With Chrome Moly A-Arms, LS1, 1998-2002

Starting from $4,741.99 kt
Model:3198176
Condition: NEW
Availability:
Please Select Options for Availability
Fitment:
Select a Vehicle or refer to the Vehicle Fitment Tab below to verify that this part fits your vehicle.
Shipping Note:Oversize 1
Qty:

Available Options

*

Can't Find your Part?

We'll find it for you. Give us a call at 877.589.9860 and we'll source that discontinued or hard to find part.

Why Choose Us?

No Brokerage or Duties - Canadian Owned & Operated - Shipped from Canada to your Door - Easy to Navigate Website - Access to New, Used & Discontinued Parts - Full Time Staff to Answer your Questions.

Disclaimer

Camaro Depot always recommends professional installation of our products. Buyer assumes risk of damage caused by improper installation.


  • Drag Series
  • Heavy Duty K-Member With Dual Tube Construction
  • Tubular Upper And Lower A-Arms With Race Quality Rod Ends
  • Wide Flanged Aluminum Step Bushings In A-Arms
  • Premium Upper And Lower Ball Joints Installed
  • Double Adjustable Race Style Bearing End Viking Shocks
  • Height Adjustment From 0” To 3” Lowering
  • 300lb/in Usa Made Front Springs, For Drag Racing
  • 43lbs Of Front End Weight Savings
  • Chromoly A-Arms Save An Additional 1-1/2lbs
  • Works With Factory Steering Rack
  • Direct Bolt In Replacement, No Welding
  • Made In The USA

Our dual tube k-member is known as the strongest in its class and can withstand wheel stand landings and street abuse while still shaving weight as well as protecting the oil pan. The rod end upper and lower a-arms reduce friction and unsprung weight while ensuring super quick weight transfer. UMI's k-member and a-arms are built from strong USA DOM tubing, precision bent, CNC notched and welded in a jig to form a solid base. Upper and lower a-arms are assembled with Teflon lined race quality rod ends and premium ball joints. The included adjustable a-arms add strength, weight reduction, reduced friction and alignment adjustments when needed. Increased caster for straight line stability can be achieved very easily with this bolt in system. Stage 5 includes Viking A226 bearing mounted front coilovers with double adjustable shocks that allow ride height, compression and rebound adjustment. The A226's feature bearing ends in place of polyurethane for friction reduction, improved response and longer lasting performance. The ride height adjustment is accomplished with the included spanner wrenches and thrust washers. The compression and rebound adjusters are clicked by hand (no tools!) and feature a total of 361 possible valving combinations. The included springs are 300lb/in and work excellent on drag race applications and vehicles with front end weight reduction. The UMI Stage 5 kit is found under many single digit F-body cars. Designed for LS1 equipped Firebird and Trans Am 1998, 1999, 2000, 2001, 2002

The Vehicle Fitment Guide is to be used as a general reference. The data has been provided by our suppliers and manufacturers and may contain errors or incorrect data. Always refer to a professional to verify correct fitment for your vehicle.
Make Model Years
Chevrolet Camaro 1998 - 2002
